Specifications: 100 & 200 Series
Type: peristaltic
100 series Pump size: 1.5”
200 series Pump size: 2.0”
100 series Transfer line: 1”-1.25” (spraying/ pumping) to 1.5” (pumping/ spraying)
200 series Transfer line:1.25”-1.5" (spraying/ pumping) to 2.0"" (pumping)
Weight: 785 lbs. - 985 lbs.
100 series Power: 115vac 15-20amp 50-60Htz (standard, other power options available)
200 series Power: 208-240vac 13.5-25amp 50-60Htz (standard, other power options available)
Air consumption: 11cfm @ 80psi (air is only used if spraying material)
*100 series Head Horiz.: 50ft
*200 series Head Horiz.: 100ft
*100 series Head Vert.: 15ft
*200 series Head Vert.: 40+ft
100 series Pumping volume: Variable speed min. 0-80 lbs per min. /0-4800 lbs per hr.0-2.8 cu yards per hr
200 series Pumping volume: Variable speed min. 0-160 lbs per min. /0-9600 lbs per hr.0-5.6 cu yards per hr
Multiple material application system, with lot's of available options.
GFRC, GFRG, PVRC, PVA, Fire Proofing, Stucco, Grouting and much more!
* Heads vary on transfer hose size and materials being used
