Pump size: 1.5”
Transfer line: 1”-1.25”
(spraying/ pumping) to 1.5” (pumping/ spraying)
Weight: 285 lbs.
Power: 115vac 15-20amp 50-60Htz
(standard, other power options available)
Max Air: 7.8cfm @ 100psi (air is
only used if spraying material)
Free Air: 4.3cfm @100psi. (compressors can be adjusted to match material)
*Head Horiz.: Varies w/material
*Head Vert.: Varies w/ material
Pumping volume: Variable
speed min. 0-80 lbs per min. /0-4800 lbs per hr.
0-2.8 cu yds per hr
Multiple material application system, with Lot's of available options.
Ship's stock plug and play ready with 25' of 1.25" transfer line and premix/ spray nozzle.
Fire Proofing, GFRC, GFRG, PVRC, PVA, Stucco, Grouting and much more!
* Heads will vary on transfer hose size and materials being used
